Features:
Display mode: B, B/B, B/M, M
Magnification: ×1.0 ×1.2 ×1.5 ×2.0
Digital focusing by through multi-point or single point, dynamic variable aperture control
Unique multi -frequency function make you no worry about upgrades
again Image processing function, gamma correction, edge enhancement
left/right, up/down, black/white for image transformation
Measurement function: distance, perimeter, area, volume, HR, fetal weight, fetal age, gestational week (EDD, BPD, GL, CRL and FL).
Clock, patient information, image notes function
Chinese & English free conversion
1024 frames dynamic playback, 64 frames storage, read at any time
It is easy to observe for local enlarge 200%

Technical Specification:
1024 frames playback
80 elements high density & multi - frequency probe
One socket can be contacted with many kinds of probes, which makes you no worry about upgrades
Gray scale: 256
Detection depth: 0-200mm.
Blind zone: ≤4mm
Vertical resolution: 1mm Horizontal resolution: 2mm
Output interface: PAL-D video output, VGA output

Standard Configuration:
One mainframe
One 3.5MHz convex probe with multi-frequency
14" black/white VGA monitor

Optional Item:
7.5 MHz linear array probe with high frequency
6.5 MHz cavity probe
17" color monitor
Pseudo
　
